Evaporators for digestate and slurry treatment

REDUCE. RECOVER. REUSE.

Goldfish, key visual of MKR Cleanwater: water reuse from digestate and slurry by evaporation

MKR Cleanwater builds thermal (DV) and electric (MVR) evaporators for food-waste, residue and agricultural biogas plants.



They reduce the volume of liquid digestate and slurry by around two thirds with waste heat, or by up to 90 % on thin liquid fractions with electricity alone, recover the nitrogen as ammonium sulphate solution (ASL), a mineral fertiliser, and leave distillate for reuse as process water. Our evaporators are built in Bavaria and run at reference plants in Germany, Switzerland and the Czech Republic that you can visit.

​

Below you find the short answers; follow the links at each topic to the page with the details.

How does evaporation treat digestate and slurry?

Digestate is what remains after anaerobic digestion (AD) in a biogas plant. After separation, its liquid fraction is mostly water.

​

A digestate evaporator boils this water off: under vacuum at 45 to 65 °C in the thermal DV series, at atmospheric pressure in the electric MVR series.

​

The ammonia leaves with the vapour and is bound by sulphuric acid in a vapour scrubber, so ammonia recovery from digestate needs no acid in the digestate itself. On request, the nitrogen can instead be recovered as aqueous ammonia (20 to 25 % NH3 by mass), without sulphuric acid. The vapour condenses to distillate, while phosphorus, potassium and organic matter stay in the concentrate.

Which evaporator fits your plant?

With usable waste heat, the thermal DV series; without it, the electric MVR series, or the DV series with a heat pump for thicker liquid fractions. Our evaporator calculator gives a first recommendation in seconds. How both series work, and how evaporation compares with other methods, is explained on our page on DV and MVR evaporators.

MKR DV4000 4-stage thermal vacuum evaporator for digestate (DV series)
MKR MVR15 electric evaporator with mechanical vapour recompression (MVR series)

DV series: with waste heat

MVR series: electric

For plants with CHP waste heat, typically food-waste and residue AD plants. The DV series is a multistage vacuum evaporator: under vacuum the digestate boils at 45 to 65 °C, so hot water at 65 to 85 °C is enough, and up to four stages use the same heat several times. Design value: 4.3 l of distillate per kWh heat; at our reference plant in Switzerland 4.5 to 4.7 l/kWh were measured at full load.

​

The DV series handles liquid fractions up to 4.5 % dry matter and reduces their volume by around two thirds. At our plants on food-waste digestate, the distillate is reused as process water in the depackaging line. Operating costs start at 5.50 € per m³ of feed.

​

One DV4000 line treats up to approx. 100 m³ of feed per day, and several lines run in parallel for larger plants. Since 2026 the DV series is also available with a heat pump: where only part of the heat is available, the heat pump covers the rest.

For sites without waste heat, such as biomethane plants that inject their gas into the grid. The MVR (mechanical vapour recompression) runs on electricity alone and at atmospheric pressure: a compressor brings the vapour back to a higher temperature and uses it to heat the evaporator again. For the whole plant this gives 22.5 l of distillate per kWh el.

​

The MVR suits thin liquid fractions up to 2.2 % dry matter and reduces their volume by up to 90 %. Thicker liquid fractions are first separated further, for example with a decanter; a laboratory test shows whether that works for your digestate. Operating costs start at 8 € per m³ of feed.

​

Sizes range from MVR05 to MVR40, with up to 4 m³ of feed per hour per module; several modules run in parallel for over 150,000 m³ a year. The vapour scrubber is built in super duplex, and the core components are the same as in our DV evaporators. Before you invest, our MVR test unit can run on site with your own digestate.

Why MKR for your project?

Because you get more than a machine: evaporators built for continuous operation on digestate, tested with your own digestate before you invest, and one contact from the first concept to long-term service.

Tested before you invest

Laboratory evaporation trial with a customer's digestate sample at MKR Cleanwater

First you receive a framework concept with a budget offer. Then we evaporate your own digestate in our laboratory; an in-house trial or on-site operation with our MVR test unit can follow. How well the laboratory test predicted later operation is shown, with period and data basis, on our page with measured operating data.

Engineering & quality

Welding a stainless steel heat exchanger in MKR's workshop in Monheim, Bavaria

Built to last, down to the last detail.

  • Stainless steel for all wetted parts

  • Acid and ASL sections entirely in corrosion-resistant plastic

  • Premium components from leading manufacturers

  • Precise in-house manufacturing and preassembly

  • Flexible, modular, expandable design with excellent accessibility

More reasons follow in the section "Why MKR evaporators?" on our reference page.

Automation & low-maintenance operation

Operator screen of an MKR DV4000 evaporator in automatic operation: four evaporator stages, vacuum, heating and cooling circuits and the next automatic CIP cleaning

Runs reliably, cleans itself, needs little attention.

  • Automatic CIP cleaning with acid and alkaline cycles

  • Automatic sensor flushing during operation, even with demanding media

  • Low maintenance: no moving parts such as brushes in the digestate

  • Quick heat-up and fast response to temperature changes

  • Complete control solution: cabinet design, build and control programming

Nutrient recovery & water reuse

Concentrate and distillate from a digestate sample after a laboratory evaporation test at MKR Cleanwater
  • ​Ammonium sulphate solution (ASL) in mineral-fertiliser quality, pH 5.5 to 6.5, without mixing acid and digestate

  • On request, aqueous ammonia (20 to 25 % NH3 by mass) instead of ASL, without sulphuric acid

  • Low-ammonium distillate for reuse as process water or for recirculation; discharge only after site-specific finishing

  • Nutrient-rich concentrate, returned to the plant or used as organic fertiliser

Three valuable products instead of disposal.

What the EU RENURE criteria mean for ASL from digestate and slurry is explained in our article.

Service & project support

Engineer at MKR Cleanwater planning a digestate evaporator project in CAD

With you from first inquiry to long-term operation.

  • Forward-thinking project planning including economic assessment

  • Expert-led implementation, including the documents you need as annexes for your permit application

  • Fast, on-schedule on-site assembly with preassembled delivery

  • Service and maintenance contracts including spare-parts management

Our evaporator know-how goes back to 1997, when MKR Metzger built its first evaporators for industry. Since 2009 we have worked on digestate, with plants in daily operation since 2013, and in 2021 the digestate and slurry division became MKR Cleanwater GmbH. How this came about is told on our page on nearly 30 years of evaporator expertise.

Where do our evaporators run?

Multistage MKR DV evaporator line in operation at a reference plant

Across Europe: our reference plants run in Germany, Switzerland and the Czech Republic, on food-waste and residue digestate, on agricultural digestate with slurry and manure, and in peat-substitute production. The oldest has been in operation since 2015; at the plant in Switzerland, a DV4000 produces around 40 m³ of distillate on a full operating day. You can visit our plants at short notice and see an evaporator working on a medium close to yours. In further target markets we work with partners on site.

​

All reference plants with their data are summarised in our reference booklet (PDF); datasheets and the introduction deck are on our downloads page.

From our blog: digestate and slurry treatment in practice

We write about regulation, technology and practice: from new EU rules such as RENURE to the question of whether evaporation or reverse osmosis suits your digestate, and what an evaporator delivers in daily operation, with measured data. New articles appear regularly; you find all of them in our blog.
